• Very short 1 second heat-up time with soft start.
• Compact dimensions - 30.5cm
long x 26cm wide and 8.5cm tall.
• Microprocessor controlled - guarantees
continuous and safe running.
• 24 volts DC, 120 amps current, 3,120 watts power.
Bench demonstration of the system.
(As you can see, the smoke output blast was so powerful it blew the paper off the bench)
The fog is totally harmless to both person and
property but is extremely unpleasant to remain in. The intruder
will make a hasty retreat and most certainly will not be able
to see to steal or cause damage.
The
small size of the unit (305mm length x 260mm width x 85mm depth) constructed from strong, tamper proof stainless steel allows
it to be easily housed in small spaces or even suspended.
The most important consideration in locating the unit is to
optimise the smoke dispersion.
On activation the unit reaches operating temperature in one second and then immediately produces impressive volumes
of smoke to hide tools and equipment or simply to make the
vehicle very unpleasant to be in.
The unit uses a coiled vaporiser and a microprocessor control circuit with in-built
safety features to prevent overheating.
The specially formulated smoke fluid is contained in a container
from where it is pumped into the vaporiser inside the
control unit.
The system utilises a simple closing circuit to activate smoke production, making it easy to install with an alarm system.
A full 750ml tank should provide around
6 minutes of total smoke production.
It is important to use quality batteries capable of a high discharge rate to power this fogger.
You would normally use 2 x 12v batteries in series to provide the power required.
The unit produces a very large volume of fog, and because of that its power consumption is relatively high.
The series connection between the batteries is critical given the high current requirement and should be of 25mm² cable (assuming less than 1 metre distance between the two batteries).
The line should be fused at 125A.
This system is safe for use
in commercial vehicles as well as vans, boats, caravans, sheds, workshops, etc.
• Heat-up time only 1 second
• Light weight, small dimensions
• Continuous high output
Power: 3,120 Watt, 120A running
Voltage: 24V
Warm up time: 1 second
Fluid consumption at continuous output: approx 90 ml/min.
Fluid tank capacity: 750 ml - ie 8 mins 20 secs fog time
Standby current:
0mA
Temperature control: Microprocessor controlled
Ambient operating temperature: between 5°C and 45°C
Dimensions (L x W x H): 30.5cm x 26cm x 8.5cm (excl. fluid tank which can be cited up to 50cm away from the unit)
Weight [excl. fluid and battery]: 3.5kg
The supplied system comprises:
- Fog generator
- Fluid tank 750ml
- 50cm fluid pipe
- External power connector with cable (suitable 125A fuse required)
- Control cable (arm / disarm and fog / stop)
- 2.5 litre container of SecuriSmoke Fluid
 Ships worldwide
|
