Concept Mini Colt 4S - Compact Smoke Generator

Concept Mini Colt 4
The stainless steel Mini Colt 4S

Mini Colt 4S smoke machine with ducting hose
Using the Mini Colt with 25mm ducting as a 'wand' for air flow tracing applications


Made in Britain

A compact, portable, stainless steel smoke machine specifically designed for clean room air flow testing.

  • Easy to use
  • Compact and robust
  • Hand portable
  • Off-power capable
  • Continuous output capable (on mains power)
  • Variable, controllable output (0 -> maximum)
  • Extremely persistent water-based smoke
  • Non-toxic, thick, dry, white smoke
  • Stainless steel, designed for cleanrooms
  • NATO codified
  • Particle size 0.2 - 0.3 micron, mass median diameter - the smallest particle size of any smoke machines

Manufactured for Pea Soup, the Mini Colt 4S is the perfect instrument to easily, cleanly and safely visualise air flow movement, patterns and extraction / air change times in laboratories and clean room environments.

The artificial smoke produced from the Mini Colt 4S is extremely persistent with a particle size of just 0.2 microns, (mass median diameter). The fluid used to produce the non-toxic smoke is a combination of purified water and pharmaceutical grade glycerine (CAS 56-81-5 / EINECS 200-289-5).

The Mini Colt can also make a considerable volume of smoke without mains power after an initial heat-up period. the unit off-mains power using the retained energy within the high mass heat exchanger, allowing you to carry the generator around, making smoke as required, without a trailing electrical lead. After being on mains for around 15 minutes, the unit will generate large amounts of smoke for around 2 minutes whilst off power, or smaller volumes for even longer.

Connected to the mains, the unit can operate continuously at full output at any smoke output volume if required.

Specifically designed for use in cleanroom and pharmaceutical cleanroom environments, as well as analytical laboratories, the Mini Colt is simple to use and reliable.

The artificial smoke from the Mini Colt 4 can be ducted using optional ducting adaptors (to suit 25, 50 and 75mm ducting) enabling the smoke to be introduced into a restricted area, duct or fume cupboard to visualise air flow patterns and areas of stagnancy very easily, safely and conveniently.

Smoke fluid from pressurised aerosol canisters makes the unit very easy to use. Each aerosol will allow approx 15 minutes of smoke production at full output, or 30 minutes at 50% output, and so on. The aerosol re-seals after each use - it does not have to be used all at once.

Construction:

  • Precision machined heat exchanger, guaranteed for life!
  • Utilises aerosol canisters for safe, convenient operation
  • Compact size, lightweight and portable
  • Available for 230v or 110v (please specify when ordering)
  • In stainless steel for cleanroom applications
General Specification (approx.) Mini Colt 4S
Size (cm) (L x W x H) 33 x 15 x 19cm
Weight 5kg
Heat exchanger wattage 1,100 watts
Power Supply 230v, 50-450Hz
(110v, 50-450Hz optional)
Warm up time from cold 5 minutes
Total smoke output dDuration of aerosol 14 minutes at maximum output (fully adjustable output volume)
Smoke output 0 - 125 m3/min @ 1.5m visibility
Particle size Consistently 0.2 - 0.3 micron, mass median diameter
Operation off the mains power supply? Yes



Information
   Particle size - explained
   Ducting smoke
   Temperature resistance of smoke
   Smoke chemical types


Red version of Mini Colt 4 with 25mm ducting adaptor and 25mm lined hose for air flow pattern visualisation

ISO 9001
Manufactured in the UK under ISO:9001

Mini Colt 4S - compact smoke generator
Mini Colt 4S (1.1kW) Basic in Stainless Steel
for 240v / 110v (dual voltage operation unit)
POA - contact us for price quotation
  We ship worldwide - contact us for shipping price if outside UK



Mini Colt 4 Smoke Fluid & Accessories
Single Persistent smoke fluid aerosol
for Mini Colt 4
£14.50
Qty:
Colt 4 aerosols (persistent smoke)
for Mini Colt 4
(Supplied in boxes of 10)
£95.00
Qty:
Refillable canister (single)
Fill with fluid (below) and pressurise to 100PSI / 7bar with a hand pump, airline or inert gas supply. Can be used 25 times + if used with care.
Overseas shipping costs are greatly reduced by ordering refillable aerosol(s) and containers of smoke fluid instead of pre-pressurised aerosols.
£49.50
Qty:
5 litres smoke fluid for use with refillable aerosol (above)
Will fill the refillable aerosol approx. 14 times.
£55.00
Qty:
High Pressure Shock Pump - double action, with gauge, used to pressurise the refillable canister (above) to 100 PSI. Small and portable, requires approx. 100 activations to pressurise canister.
Photo at left shows pump next to refillable canister.
£49.50
Qty:
High Pressure Stirrup Pump - with gauge, used to pressurise the refillable canister (above) to 100 PSI. Larger than shock pump above, but only requires around 5 actions to pressurise the canister.
Photo at left shows pump next to refillable canister.
£49.50
Qty:
High Pressure Foot Pump
- with gauge, used to pressurise the refillable canister (above) to 100 PSI. Smaller than stirrup pump above, but only requires around 25 actions to pressurise the canister but using your leg instead of your arm.
Photo at left shows refillable canister next to pump.
£49.50
Qty:
Premium PELI Transport Case for Mini Colt 4 smoke machine.
with custom foam cut-out to fit the Mini Colt 4 machine, power lead, 2 aerosols. Colour: orange.
IP67 certified for military, broadcast, marine, photography, industrial use. Air tight, corrosion proof, water tight, shock proof, sand and dust proof.
£435.00
Qty:
DUCTING ADAPTORS & HOSE


A ducting adaptor easily attaches to the front of the machine to allow secure connection of ducting hose to allow smoke to be positioned precisely, in hard to reach places or inside fume cupboards, etc.

All our ducting hoses are internally lined to be smooth thereby reducing frictional losses and particle impaction.

25mm diameter ducting adaptor
Easily attaches to the front of the Mini Colt and secures the ducting hose in position.
£60.00
Add to basket
25mm silicon lined flexible ducting x 2 metre length
See photo at top. Stays rigid - ideal for clearance and air flow tests to use as a smoke 'wand'.
£82.00

Add to basket

25mm silicon lined flexible ducting x 4 metre length
As above, but a 4 metre length
£150.00

Add to basket


An alternative to the Mini Colt 4 is the Pea Soup Rocket, which produces just the same high quality smoke, but is also available with a 5 metre wired remote control option and in a Turbo (2.2kW) high output version, yet is still small (only 5cm longer and 1.5cm taller than the Mini Colt 4). It can also be used off-power for up to 2 minutes just the same as the Mini Colt.

Related products:

The Pea Soup Micro Rocket is a quick dispersing battery powered smoke machine.
Click on the image below to find out more:
