Features:
- 600w heater
- Contoured shell design
- 7 minute heat up time
- Approx. 200m3 smoke output (7062 cubic feet/min)
- Remote Control with auto timer
- Handle with hanging point
- Continuous output
- Output level control
- 1 litre fluid container
- Direct thermal protection
- Optional DMX module
DIRECT THERMAL PROTECTION DEVICE (DTPD)
This small yet crucial component is the last line of defence
against catastrophic failure. This machine's DTPD is made from a solid
ceramic composite. This guarantees extremely precise overheat
monitoring and is unaffected by ambient temperature changes.
Electronic Pump Ramping (EPR)
EPR is an intelligent means
of warning of a drop in temperature which could result in
'wet smoke' (residue). The pumps respond to this
signal by running slower and pumping less fluid, thus allowing
the heaters to restore optimum operational temperature. This
guarantees a continuous flow of smoke using highly efficient,
lower wattage heaters.
Soft Start Electronics
The 'crack' created during the initial burst of smoke is caused
by the pump pressure overcoming the incredible back pressure
of the heat exchanger. The unique Soft Start Electronics in this machine
gradually powers the pump, eliminating this crack and ensuring
a quieter and smoother operational level following initial
start up.
Compact Timer Remote
Jem hand-held remotes are safe, user friendly, low voltage
remotes which offer precision auto-timer and output level
controls. The auto-timer is simple to set with 'Fog On' adjustable
between 0 and 15 seconds, while the delay period is pre-set
at 1 minute. Once the reliable timer is engaged you are free
to concentrate on the music and light.
Fluid Container (1 litre)
All Jem smoke, haze and heavy fog machines are designed to
carry removable fluid containers of varying sizes depending
on the model's application. The removable container makes
for quicker refills and protects the machine from damage through
spillage in transit.
Heat Exchangers (600W)
All Jem heat exchangers are designed for high efficiency performance.
Only the purest grade LM24 aluminium is used in the production
process which eliminates the risk of porosity (pockets of
gas within the casting which can cause heater failure). All
heat exchangers contain cuprous helicoils of at least 2.8
metres in length, ensuring a continuous flow of pure, dry,
white smoke.
Download
user manual
in Adobe Acrobat format
|
